Image similar
Image similar
WIKA Check valve 9091009 910.11 400 bar (max) 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Design A, with clamping sleeve
- Permissible nominal pressure: PN max. 400 bar
- Process/device connection: G1/2B tap + G1/2 clamping sleeve
- Design: With separately lockable test connection to DIN 16272 standard
- Material packing PTFE
- Test connection M20 x 1.5
- Material body: Burnished steel
- Permissible temperature for the test substance: -10...+120°C.
- Product type
Check valve
- Type
With separately lockable test connection to DIN 16272 standard
- Operating temperature
-10 up to 120 °C
- Min. operating temperature
-10 °C
- Max. operating temperature
120 °C
- Manufacturer part #
9091009
- Material (details)
Gunmetal finish
- Connection
G1/2B adapter + G1/2 clamping sleeve
- Max. operating pressure
400 bar
- Pressure range
400 bar (max)
Documents & Downloads
Datasheet
Datasheet 3524878 WIKA Check valve 9091009 910.11 400 bar (max) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3524878 WIKA Check valve 9091009 910.11 400 bar (max) 1 pc(s)
Description
DIN-Shut valve
Technical data according to data sheet AC 09.02
Design: With separately lockable test connection to DIN 16272 standard
Material body: Burnished steel
Material packing PTFE
Permissible temperature of the measuring substance: -10...+120°C
Permissible nominal pressure: PN max. 400 bar
Design A, with clamping sleeve
Process/device connection: G1/2B tap + G1/2 clamping sleeve
Test connection M20 x 1.5
This text is machine translated.
Technical data according to data sheet AC 09.02
Design: With separately lockable test connection to DIN 16272 standard
Material body: Burnished steel
Material packing PTFE
Permissible temperature of the measuring substance: -10...+120°C
Permissible nominal pressure: PN max. 400 bar
Design A, with clamping sleeve
Process/device connection: G1/2B tap + G1/2 clamping sleeve
Test connection M20 x 1.5
This text is machine translated.
