Name: WIKA Protective pipe (welded) 3907570 SWT52S 1 pc(s)
Brand: WIKA
SKU: 3525175

A brass hex bushing with a threaded neck and a long cylindrical body is shown against a white background. It's used in plumbing applications.

Image similar

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Process connection: Welding pin 24 mm
Protective tube material: CrNi steel
Construction: Multi-part, for welding
Connection to the thermometer: Locking screw
Drilling: For thermometer with 8 mm plunge shaft
Protective tube outer diameter 10 mm
Mounting length l2 180 mm

Product type: Protective pipe (welded)

Manufacturer part #: 3907570

Dim: (Ø x D) 10 mm x 180 mm

Connection: Welding pin 24 mm

Depth: 180 mm

(Ø): 10 mm

Pipe Ø: 10 mm

Documents & Downloads

Datasheet

Datasheet 3525175 WIKA Protective pipe (welded) 3907570 SWT52S 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3525175 WIKA Protective pipe (welded) 3907570 SWT52S 1 pc(s)

Description

Protective tube SWT52S for welding (multi-part)
High-quality for thermometer type 52
Technical data according to data sheet: TW 90.11
Construction: Multi-part, for welding
Process connection: Welding pin 24 mm
Connection to the thermometer: Locking screw
Drilling: For thermometer with 8 mm plunge shaft
Protective tube outer diameter 10 mm
Protective tube material: CrNi steel
Mounting length l2 180 mm

This text is machine translated.
