Wima 1 pc(s) FKP thin film capacitor Radial lead 100 nF 6000 V DC, 700 V AC 10 % 37.5 mm (L x W x H) 41.5 x 35.0 x 50.0
Part number:
Item no:
Packaging type
Bulk
Product type
FKP thin film capacitor
Type
Radial lead
Capacity (elec.)
100 nF
Nominal voltage
6000 V DC
700 V AC
Datasheet (PDF)
Highlights & Details
Wima FKP thin film capacitor
Our service for you
Technical specifications
- Series FKP1
- Design_1: Radial
- Applications: Pulse and frequency load applications like e.g. switching power supplies, inverter circuits in drive and power technology, deflection circuits in television and monitoring technology, electronic ballasts
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Pitch_1:37.5 mm
- Climate category IEC 55/100/56
- Capacitance 100 nF
- Capacity_1: 100
- Capacitance unit: NF
- Capacity Tolerance 10%
- Dielectric: Metallized PP film
- Nominal voltage DC 6,000 V
- Nominal voltage AC 700 V
- Reliability: 1 fit
- Lifetime_1: 300,000 h
- Insulation value in sec.: 30,000 sec.
- Packaging type
Bulk
- Product type
FKP thin film capacitor
- Type
Radial lead
- Dim
(L x W x H) 41.5 x 35.0 x 50.0 mm
- Capacity (elec.)
100 nF
- Nominal voltage
6000 V DC
700 V AC
- Tolerance ±
10 %
- Material
PP
- Connection
THT
- Length
41.5 mm
- Width
35.0 mm
- Height
50.0 mm
- CS
37.5 mm
- Min. temperature
-55 °C
- Max. temperature
100 °C
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
FKP1Y031007J00KSSD
- Operating temperature (max.)
100 °C
- Operating temperature (min.)
-55 °C
Documents & Downloads
Datasheet
Datasheet 3464101 Wima 1 pc(s) FKP thin film capacitor Radial lead 100 nF 6000 V DC, 700 V AC 10 % 37.5 mm (L x W x H) 41.5 x 35.0 x 50.0
User & Safety Instructions
User & Safety Instructions 3464101 Wima 1 pc(s) FKP thin film capacitor Radial lead 100 nF 6000 V DC, 700 V AC 10 % 37.5 mm (L x W x H) 41.5 x 35.0 x 50.0
Description
Wima FKP capacitor series FKP1
