Wima MKS4D032202B00KSSD 1 pc(s) MKT thin film capacitor Radial lead 220 nF 100 V DC, 63 V AC 10 % 7.5 mm (L x W x H) 10.
Part number:
Item no:
Product type
MKT thin film capacitor
Type
Radial lead
Capacity (elec.)
220 nF
Nominal voltage
100 V DC
63 V AC
Tolerance ±
10 %
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.33842
50
9% = € 0.03
€ 0.30759
100
13% = € 0.04
€ 0.29527
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.33842 / piece)
€ 0.34
plus VAT.
14-day return policy included
Technical specifications
- ESD Packaging: No ESD
- Series: MKS4
- Design_1: Radial
- Applications:For general DC-applications: Bypass, blocking, coupling and decoupling, smoothing/screening, timing
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: Dielectric made of polyethylene terephthalate (PET) foil
- Receipts: Metalised
- Covering: Solvent-resistant, flame-inhibiting plastic casing with epoxide-resin cast, UL94V-0
- Connections made of tin-plated wire
- self-healing
- Pitch_1:7.5 mm
- Climate category IEC 55/105/56
- Capacitance 220 nF
- Capacity_1: 220
- Capacitance unit: NF
- Capacity Tolerance 10%
- Dielectric: Metallized PET film
- Nominal voltage DC 100 V
- Nominal voltage AC 63 V
- Pulse load 12 V/µs
- Reliability: 2.0 fit
- Lifetime_1: 300,000 h
- Insulation resistance_1: 15,000 MOhm
- Product type
MKT thin film capacitor
- Type
Radial lead
- Dim
(L x W x H) 10.0 x 2.5 x 7.0 mm
- Capacity (elec.)
220 nF
- Nominal voltage
100 V DC
63 V AC
- Flank steepness
12 V/µs
- Tolerance ±
10 %
- Material
PET
- Connection
Wire
- Length
10.0 mm
- Width
2.5 mm
- Height
7.0 mm
- CS
7.5 mm
- Min. temperature
-55 °C
- Max. temperature
105 °C
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
MKS4D032202B00KSSD
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3523669 Wima MKS4D032202B00KSSD 1 pc(s) MKT thin film capacitor Radial lead 220 nF 100 V DC, 63 V AC 10 % 7.5 mm (L x W x H) 10.
User & Safety Instructions
User & Safety Instructions 3523669 Wima MKS4D032202B00KSSD 1 pc(s) MKT thin film capacitor Radial lead 220 nF 100 V DC, 63 V AC 10 % 7.5 mm (L x W x H) 10.
Description
Wima MKT capacitors MKS4 100V 10%
