Wima MKX2AW31004B00KSSD MKP suppression capacitor Radial lead 100 nF 305 V AC 10 % 1 pc(s)
Part number:
Item no:
Product type
MKP suppression capacitor
Type
Radial lead
Connection
Wire
Capacity (elec.)
100 nF
Tolerance ±
10 %
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.67622
10
8% = € 0.05
€ 0.62178
25
11% = € 0.08
€ 0.60001
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.67622 / piece)
€ 0.68
plus VAT.
14-day return policy included
Technical specifications
- ESD Packaging: No ESD
- MKP-X2 series
- Approvals: CULus,ENEC10
- Design_1: Radial
- Applications: Class X2 suppression applications for EMC requirements: Line parallel capacitor between phase and neutral or phase and phase, general requirements, T 2.5 kV peak pulse voltage
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: Winding technology, class X2
- Dielectric made of polypropylene (PP) Film
- Receipts: Metallized plastic film
- Covering: Solvent-resistant, flame-retardant plastic casing with epoxy resin casting (UL94V-0)
- Connections made of tin-plated wire
- Safe regeneration characteristics
- The low-attenuation design with low ESR provides a high degree of interference suppression.
- Pitch_1:15 mm
- Climate category IEC 55/105/56
- Capacitance 100 nF
- Capacity_1: 100
- Capacitance unit: NF
- Capacity Tolerance 10%
- Dielectric: Metallized PP film
- Nominal voltage AC 305 V
- Class X2
- Reliability: 2 fit
- Lifetime_1: 300,000 h
- Insulation resistance_1: 15,000 MOhm
- Product type
MKP suppression capacitor
- Type
Radial lead
- Connection
Wire
- Capacity (elec.)
100 nF
- Nominal voltage
305 V AC
- Tolerance ±
10 %
- Length
18.0 mm
- Width
5.0 mm
- Height
11.0 mm
- CS
15 mm
- Material
Polypropylene
- Min. temperature
-55 °C
- Max. temperature
105 °C
- Content
1 pc(s)
- Dim
(L x W x H) 18.0 x 5.0 x 11.0 mm
- RoHS-compliant
Yes
- Type
MKX2AW31004B00KSSD
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3527550 Wima MKX2AW31004B00KSSD MKP suppression capacitor Radial lead 100 nF 305 V AC 10 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3527550 Wima MKX2AW31004B00KSSD MKP suppression capacitor Radial lead 100 nF 305 V AC 10 % 1 pc(s)
Description
Wima MKP suppression capacitor series M
