Wiska 10016327 Cable gland shockproof, with seal M75 Brass Ecru 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M75
Type
straight
Material
Brass
Clamp Ø
44 mm
Technical specifications
- Thread pitch 1.5 mm
- Hexagonal corner dimensions 76 mm
- Type of seal: Sealing ring
- EMC design: Yes
- Shielded: Yes
- Product type
Cable gland
- Features
shockproof
with seal
- Factory colour
Ecru
- External thread
M75
- Type
straight
- Material
Brass
- Clamp Ø
44 mm
- Terminal Ø (max.)
48.5 mm
- Thread length
16 mm
- Min. temperature
-40 °C
- Max. temperature
+100 °C
IP54
- Spanner size
70 mm
- Halogen-free
Yes
- Content
1 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
10016327
- Type
EKVM 72/75-Z48
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2477096 Wiska 10016327 Cable gland shockproof, with seal M75 Brass Ecru 1 pc(s)
Description
EMC cable entry according to DIN 89280 for shielded cables.
This robust cable entry is particularly suitable for use in harsh industrial environments.
The seals have good resistance to ozone, weather and aging influences.
