Yageo CFR-25JB-52-120R Carbon film resistor 120 Ω Axial lead 0207 0.25 W 5 % 1 pc(s) Bulk
Part number:
Item no:
Packaging type
Bulk
Product type
Carbon film resistor
Type
Axial lead
Resistance
120 Ω
Power rating
0.25 W
Datasheet (PDF)
Highlights & Details
Yageo coal-coated 0207 0.25W 5% 120R loose
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series CFR-25
- Size 0207
- Delivery form: Loose
- Length: 61.7 mm.
- Diameter, Resistance element 2.3 mm
- Diameter, connection wire 0.58 mm
- Solder carrying capacity 350°C 5 s.
- Resistance tolerance: ±5 %
- Rated output: 0.25 W
- Max. OPERATING VOLTAGE (DC) 250 V DC
- Max. OPERATING VOLTAGE (AC) 250 V AC
- Nominal voltage: 250 V
- Max voltage 500 V
- Packaging type
Bulk
- Product type
Carbon film resistor
- Type
Axial lead
- Type
0207
- Resistance
120 Ω
- Power rating
0.25 W
- Tolerance ±
5 %
- Length
5.7 mm
- (Ø)
2.3 mm
- Content
1 pc(s)
- Dim
(Ø x L) 2.3 mm x 5.7 mm
- RoHS-compliant
Yes
- Type
CFR-25JB-52-120R
- Mounting type
PCB mount
- Operating temperature (max.)
155 °C
- Operating temperature (min.)
-55 °C
- Insulation resistance
10,000 MΩ
Documents & Downloads
Datasheet
Datasheet 3464264 Yageo CFR-25JB-52-120R Carbon film resistor 120 Ω Axial lead 0207 0.25 W 5 % 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3464264 Yageo CFR-25JB-52-120R Carbon film resistor 120 Ω Axial lead 0207 0.25 W 5 % 1 pc(s) Bulk
Description
Carbon film resistors 1/4W 5% 0207
