Yealink Yealink Video Collaboration Bar A10-010 Conferencing system Multicolour
EAN:
Part number:
Item no:
Yealink Meeting Bar A10-010
Highlights & Details
- Video Collaboration
- Bluetooth Automatic picture setting
- 4K Ultra HD 3840 x 2160 pixels 30 fps
- Built-in speaker
- Direct current connection (DC) Ethernet/LAN 10,100,1000 Mbit/s WLAN
- Single camera
- Energy source: AC
- Black/Grey
Technical specifications
- Product color: Black, gray
- Product type: Video collaboration
- HD type 4K Ultra HD
- USB-Plug USB Type-A,USB Type-C
- Installed operating system: Android 10
- Product type
Conferencing system
- Factory colour
Multicolour
- Bluetooth
4.2
- Bluetooth
Yes
- Depth
68 mm
- Height
82 mm
- Width
380 mm
- No. of USB type A 3.1 / 3.2 1st Gen
1 x
- Charging capacity (max.)
7.5 W
- Charging capacity (min.)
2.5 W
- 10/100/1000 Mbps ports
1 x
- Power consumption (ON)
10.5 W
- Power supply (details)
100 - 240 V
- Safety
256-bit AES
EAP-TLS
MSCHAPv2
PEAP
TLS
- Weight
2.103 kg
- Wi-Fi
Yes
- UKCA
yes
- Audio system full duplex
yes
- Operating temperature (T-T)
0 - 40 °C
- AC adapter included
yes
- Line-in
yes
- Line-out
yes
- Ethernet LAN
yes
- Cable lock slot
yes
- Wall mountable
yes
- Speaker power
5 W
- Remote control included
yes
- Microphone sensitivity
88 dB
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
- Microphone in
yes
- DC-in jack
yes
- Built-in speaker(s)
yes
- Microphone mute
yes
- DC output voltage
48 V
- Networking cable length
3 m
- HDMI cable length
1.8 m
- HDMI output ports quantity
1
- Quick start guide
yes
- Camera privacy shutter
yes
- Number of microphone arrays
8
- Auto framing
yes
- Reset slot
yes
- Power consumption (idle)
10 W
- DC output current
0.7 A
- Operating relative humidity (H-H)
10 - 95 %
- Echo cancellation
yes
- Maximum video resolution
3840 x 2160 p
- Maximum frame rate
30 fps
- PTZ control
yes
- Storage temperature (T-T)
-30 - 70 °C
- Auto-tracking
yes
- Number of cameras
1
- Horizontal field of view
105°
- Diagonal field of view
120°
- Power consumption (max)
14 W
- Motion sensor
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3386415 Yealink Yealink Video Collaboration Bar A10-010 Conferencing system Multicolour
Description
The Yealink MeetingBar A10 is an all-in-one video bar designed for small rooms (1-7 people) and home offices. The built-in 4k camera with 120° field of view captures details accurately and with great colors. AI-supported functions such as auto framing, speaker tracking and Smart Gallery provide for a concentrated view without distractions. The integrated 8 MEMS beamforming microphones record speech from all directions and a full duplex audio algorithm with KI-supported noise suppression delivers clear sound for both the sides, even if you speak at the same time.
