YingJiao LED driver 15 W 0.625 A 24 V 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Brand.47802063 YSL20F-15W LED-SNT IP20 plastic case
- 24 V
- 0.625 A
Technical specifications
- not dimmable
- Operation maintenance 300000 h
- MTBF 2000000 h
- Product type
LED driver
- Dim
(L x W) 103 mm x 35.5 mm
- Output voltage (max.)
24 V
- Protection class
IP20
- Connection
Screw terminal
- Max. power
15 W
- No. of outputs
1 x
- Output current (min.)
0.625 A
- Input voltage (max.)
240 V AC
- Min. input voltage
220 V AC
- Power range
15 W (max)
- Width
35.5 mm
- Length
103 mm
- Max. temperature
+45 °C
- Min. temperature
-20 °C
- Efficiency
88 %
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3435676 YingJiao LED driver 15 W 0.625 A 24 V 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
