YingJiao YCL40-2401660 LED driver 40 W 1.66 A 24 V 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Fire.47802063 YSL40-40W LED-SNT IP67 plastic
- 24 V
- 1.66 A
Technical specifications
- not dimmable
- Operation maintenance 300000 h
- MTBF 2000000 h
- Product type
LED driver
- Dim
(L x W) 148 mm x 40 mm
- Output voltage (max.)
24 V
- Operating voltage
230 V
- Protection class
IP67
- Connection
Braid
- Max. power
40 W
- No. of outputs
1 x
- Output current (min.)
1.66 A
- Input voltage (max.)
240 V AC
- Min. input voltage
220 V AC
- Power range
40 W (max)
- Width
40 mm
- Length
148 mm
- Max. temperature
+45 °C
- Min. temperature
-20 °C
- Efficiency
86 %
Documents & Downloads
Datasheet
Datasheet 3435657 YingJiao YCL40-2401660 LED driver 40 W 1.66 A 24 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3435657 YingJiao YCL40-2401660 LED driver 40 W 1.66 A 24 V 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
