YingJiao YSL15T-1201500 LED driver 18 W 1.5 A 12 V 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Brand.47802063 YSL15T-18W LED-SNT IP20 plastic
- 12 V
- 1.5 A
Technical specifications
- not dimmable
- Operation maintenance 300000 h
- MTBF 2000000 h
- Product type
LED driver
- Dim
(L x W) 160 mm x 30 mm
- Output voltage (max.)
12 V
- Operating voltage
230 V
- Protection class
IP20
- Connection
Screw terminal
- Max. power
18 W
- No. of outputs
1 x
- Output current (min.)
1.5 A
- Input voltage (max.)
240 V AC
- Min. input voltage
220 V AC
- Power range
18 W (max)
- Width
30 mm
- Length
160 mm
- Max. temperature
+45 °C
- Min. temperature
-20 °C
- Efficiency
88 %
Documents & Downloads
Datasheet
Datasheet 3435672 YingJiao YSL15T-1201500 LED driver 18 W 1.5 A 12 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3435672 YingJiao YSL15T-1201500 LED driver 18 W 1.5 A 12 V 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
