Technical specifications
- Product type
Sheathed cable
- No. of leads
2 x
- Content
100 m
- Cross section (each core)
0.8 mm
- Insulation material
PVC
- Cable features
single core
- Cable type
YR
- Manufacturer part #
YR 2x0,8
- Max. length sold by the metre
100 m
- Sold per metre
Yes
- Cross section
2 x 0.8 mm
- Max. temperature range (fixed installation)
+70 °C
- Min. temperature range (fixed installation)
-5 °C
- Type
YR 2x0,8
0.8 mm²
Polyvinyl chloride (PVC)
Colour
25 kg/km
No
None
100 V
White
Round
0.8 mm
Copper
Polyvinyl chloride (PVC)
Class 1 = solid
None
-5-70 °C
Several
FALSE
2
None
70 °C
None
4.2 mm
FALSE
FALSE
FALSE
FALSE
FALSE
Bare
None
None
None
None
30 mm
FALSE
Round
FALSE
FALSE
FALSE
FALSE
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2984904 YR 2x0,8 Sheathed cable YR 2 x 0.8 mm 100 m
Description
YR PVC bell cable, PVC insulated switch wires, single-wire, rated voltage 100V, temperature range -5°C to +70°C, for fixed installation as an insulation cable on and under plaster, not for heavy current installation purposes, for signal transmission in telecommunications and door systems, etc.
