Zotac Barebone ZBOX-MI648-BE Intel® Core™ i5 i5-1340P ZBOX-MI648-BE
EAN:
Part number:
Item no:
Zotac ZBOX-MI648-BE 2.5 cm (1 inch) Barebone
Highlights & Details
- Display: 2.5 cm (1 inch)
- Intel® Core™ i5 i5-1340P 13th Gen (Raptor Lake) 12 core(s) / max. 4.6 GHz
- RAM: 0 GB DDR5 RAM 5200 MHz
- Intel Iris Xe graphics
- w/o OS
Technical specifications
- Product type
Barebone
- Model
ZBOX-MI648-BE
- Display (cm)
2.5 cm
- Screen size diagonal (inches)
1 inch
- CPU series
Intel® Core™ i5
- CPU
Intel® Core™ i5 i5-1340P
- Processor/type
i5-1340P
- Processor generation
13th Gen (Raptor Lake)
- Processor cores (No.)
12 x
- CPU speed
1.9 GHz
- CPU turbo clock speed (max.)
4.6 GHz
- CPU cache
12 MB
0 GB
- RAM type
DDR5 RAM
- Memory clock speed
5200 MHz
- No. of memory slots
2
- RAM / Max. upgrade
64 GB
- Onboard graphics card
Yes
- Onboard graphics card (GPU manufacturer)
Intel
- Onboard graphics card (version)
Iris Xe graphics
- Dedicated graphics card
No
- SSD size (total)
0 GB
- SSD
0 GB
- SSD connection
M.2 PCIe NVMe
- HDD capacity (total)
0 GB
- Hard drive
0 GB
- Drive
w/o hard drive
- Mobile internet
WiFi
- Keyboard layout
Keyboard not included
- No. of Gigabit LANs
2 x
- No. of HDMI ports
1 x
- No. of Thunderbolt IFs
1 x
- No. of USB type A 3.1 / 3.2 1st Gen
4 x
- Interfaces
USB A (USB 3.2 1st gen)
HDMI™
Microphone (3.5 mm jack)
Headphone jack (3.5 mm)
RJ45
Thunderbolt 4
Wi-Fi 6 (IEEE 802.11ax)
- Factory colour
Black
- Width
149.5 mm
- Height
28.5 mm
- Depth
149.5 mm
- Weight
1.251
- PSU power
40 W
- Operating system (Version)
w/o OS
- Display size
- 23 inch
- Display
2.5 cm (1 inch)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3018356 Zotac Barebone ZBOX-MI648-BE Intel® Core™ i5 i5-1340P ZBOX-MI648-BE
Description
The award-winning design of the ZBOX Edge MI648 combines an ultra slim housing with an Intel core i5 processor. The ZBOX Edge MI648 features efficient thermal design, energy management and good ventilation, yet still offers a remarkably flat design and comprehensive I/O connectivity. The MI648 is an excellent gateway for efficient edge computing or everyday computer tasks in companies, offices or at home.
This text is machine translated.
This text is machine translated.
Features
- 12-core Intel core i5 processor
- Ultra-flat with a height of just 28.5 mm
- Intel iris Xe graphics
- Up to 64GB DDR5 RAM support
- M.2 NVMe PCIe 4.0 , M.2 PCIe 3.0 Slot
- Windows 11 ready
- 4K@60Hz display support via HDMI, DisplayPort and DisplayPort via Thunderbolt 4
- Triple display support
- Fast data transfer with USB 3.1
- Dual Gigabit Ethernet, Wi-Fi 6 and Bluetooth 5.2
- VESA mount ready
Hints
HDMI® is a registered trademark of HDMI Licensing LLC
Image may differ from actual product.
