ZyXEL GS1900 Series GS1900-48HPv2 - switch Smart - 48 x 10/100/1000 (24 PoE+)
EAN:
Part number:
Item no:
Datasheet (PDF)
ZyXEL GS1900 Series GS1900-48HPv2 - switch Smart - 48 x 10/100/1000 (24 PoE+)
Highlights & Details
- Intelligent PoE+ supplies more devices
- Fast Gigabit performance - designed specifically for SMEs
- Easy and intuitive management
Technical specifications
- + 2 x Gigabit SFP (uplink) - rack mountable, desktop - PoE+ (170 W)
- Product type
Network switch
- LAN transfer rate
1000 MBit/s
- Transfer rate
100 GBit/s
- Working principle
Managed switch
- Ethernet ports
48
- IEEE 802.3af PoE
24
- PoE ports
24
- SFP ports
2 x
- 10/100/1000 Mbps ports
48 x
- Fibre-optic ports
2
- Auto-uplink at each port
Yes
- Jumbo frames
Yes
- MAC addresses
8000
- Weight
5.015
- Width
44.1 cm
- Height
4.4 cm
- Depth
27 cm
- Type
Switch
- Rack size
483 mm (19")
- Interfaces
RJ45
- Factory colour
Multicolour
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3732976 ZyXEL GS1900 Series GS1900-48HPv2 - switch Smart - 48 x 10/100/1000 (24 PoE+)
User & Safety Instructions
User & Safety Instructions 3732976 ZyXEL GS1900 Series GS1900-48HPv2 - switch Smart - 48 x 10/100/1000 (24 PoE+)
Description
The PoE models have the standard PoE consumption mode. Only the energy actually needed is delivered to your connected equipment, the rest is reserved and the energy budget optimized. This means that a single switch can power more APs, IP cameras, and VoIP phones, WAS can help your business achieve better ROI. All models support IEEE 802.3at and offer a maximum of 30 W per port. The GS1900 series includes non-blocking full bandwidth switches with up to 1 Gbps per port. If an unmanaged switch has been used before, it is an ideal upgrade and is a perfect choice for SMEs who want to enjoy high-speed applications on the business network at full, non-blocking wire speed. The switches of the Smart managed GS1900 series possess a web-based interface for an easy management of advanced functions such as VLAN, QoS, IGMP snooping, link aggregation (LAG), IPv6 and DoS protection. In addition, the user-friendly wizard helps to quickly go through the setup, configuration and even advanced settings.
This text is machine translated.
This text is machine translated.
Features
- ZyXEL GS1900 series GS1900-48HPv2 - switch - 48 connections - Smart - can be mounted on rack
- Device type: Switch – 48 connections – Smart
- Housing Type : Rack mountable
- Sub-type : Gigabit Ethernet
- Ports : 48 x 10/100/1000 (24 PoE+) + 2 x Gigabit SFP (uplink)
- Power over Ethernet (PoE) : PoE+
- PoE budget : 170 W.
- Performance : Switching capacity: 100 Gbps
- Transmission power 74 Mpps
- Size of the MAC address table : 8000 entries
- Jumbo Framework Support : 9KB
- Routing protocol : IGMP, IGMPv2, IGMPv3, STP, RSTP, MSTP
- REMOTE MANAGEMENT PROTOCOL : RADIUS, TACACS+, ICMP, SNMP 1, SNMP 2, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, HTTP, NTP, DHCP, RSTP, IPV6
- Features : 525 KB packet buffer, EEE, flow control, CoS, MSTP support, RRSTP, STP support, back pressure support, full duplex mode, half duplex mode, Store-and-forward, auto-uplink (auto MDI/MDI-X), dual firmware images, VLAN tagging, guest VLAN, voice VLAN, storm control, SPQ, WRR queuing, frequency limit, QoS, ToS, MAC address filter, protection against DoS attacks, IGMP snooping, IPv6 support, ICMP, syslog support, LLDP support, LLDP-MED, Firmware upgradeable, DHCP client, port mirroring, schedule PoE, MIB II, LAG, priority allocation, port security, NDP, Smart fan, Slot for security lock (cable lock available separately)
- Product certifications : IEEE 802.3at, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1p, IEEE 802.3af, IEEE 802.1d, IEEE 802.1w, IEEE 802.11g, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1x, IEEE 802.1AB (LLDP)
- Power supply : AC 100-240 V (50/60 Hz)
- Dimensions (width x depth x height): 44.1 cm x 27 cm x 4.4 cm
- Weight: 3.55 kg
