Aim TTi EX4210R Bench PSU (adjustable voltage) 0 - 42 V DC 0 - 10 A 420 W No. of outputs 1 x
EAN:
Part number:
Item no:
Number
Total (€ 763.87 / piece)
€ 763.87
plus VAT.
Highlights & Details
Laboratory power supply aim TTi EX4210 R, 42 V/10 A, 420 W
- No. of outputs 1 x
- 0 - 42 V DC / 0 - 10 A
- 420 W
Technical specifications
- Type
EX4210R
- Product type
Bench PSU (adjustable voltage)
- No. of outputs
1 x
420 W
- Dim
(L x W x H) 140 x 320 x 160 mm
Manufacturer's standards (no certificate)
- Input voltage
115 V AC
230 V AC
- Weight
3.6 kg
- Connections
Spring connector
- Output voltage (max.)
42 V DC
- Output voltage (min.)
0 V DC
- Max. output current
10 A
- Output current (min.)
0 A
- Width
320 mm
- Height
160 mm
- Length
140 mm
- Residual ripple
1 mVrms
- Max. temperature
+40 °C
- Min. temperature
+5 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1418423 Aim TTi EX4210R Bench PSU (adjustable voltage) 0 - 42 V DC 0 - 10 A 420 W No. of outputs 1 x
Information
Information 1418423 Aim TTi EX4210R Bench PSU (adjustable voltage) 0 - 42 V DC 0 - 10 A 420 W No. of outputs 1 x
Description
The compact switched-mode power supplies with mixed mode control of the series EX-R offer an output power of 175 to 420 W. The models have a high-resolution, four-digit measurement display and switchable connections for remote sensing.
This text is machine translated.
This text is machine translated.
Features
- Mixed Mode Control with linear endre locking
- Constant voltage or constant current with automatic crossover
- Four-digit display with 10 mV to 1 mA resolution
- Switchable Connections for remote sensing for perfect control on the load
- DC output switch allows voltage/current configuration when not connected load
- Safety connecting terminals for the recording of 4 mm plugs with fixed protective sleeve, fork connector and wires.
