FLIR CM275 Clamp meter Built-in thermal imager, Data logger CAT IV 600 V, CAT III 1000 V

  • Item no.: 1629399
  • Manufacturer no.: CM275
  • EAN: 0793950372753

The clip-on ammeters CM174 and CM275 from FLIR thermal imaging and electrical measurement to combine high-performance inspection, troubleshooting and diagnostic tools. Due to the infrared-controlled measurement (IGM™), they offer a quick and reliable…

  • Warranty: 24 months
  • Manufacturer: FLIR
  • Item no.: 1629399
  • Manufacturer no.: CM275
  • EAN: 0793950372753

The clip-on ammeters CM174 and CM275 from FLIR thermal imaging and electrical measurement to combine high-performance inspection, troubleshooting and diagnostic tools. Due to the infrared-controlled measurement (IGM™), they offer a quick and reliable…

  • Warranty: 24 months
  • Manufacturer: FLIR
  • Bolometer matrix: 160 x 120
  • Field of view: 50.0° x 38°
  • Temperature range: -10 to +150 °C
  • Focus: fix
  • Color Palettes: iron, Rainbow, Grayscale
  • Temperature accuracy: 3%.
Voltage reading range DC (min.) 0.1 V
Voltage DC reading range (max.) 1000 V
V AC reading range (min.) 0.1 V
V AC reading range (max.) 1000 V
Amperage reading range DC (min.) 0.1 A
A DC reading range (max.) 600 A
A AC reading range (min.) 0.1 A
Amperage reading range AC (max.) 600 A
Reading range - resistance 6000 K (±1.0%)
Reading range - capacity 1000 µF (± 1.0%)
Measurement type True RMS
Interfaces Bluetooth®
Height 48.5 mm
Width 97 mm
Length 255 mm
Weight 460 g
Calibrated to
Manufacturer's standards (no certificate)
Reading category CAT IV 600 V , CAT III 1000 V
Voltage metering AC/DC
Current reading AC/DC
Type CM275
Features Built-in thermal imager , Data logger
Opening range of current clamps 35 mm
Product type Clamp meter

Technical data

  • Bolometer matrix: 160 x 120
  • Field of view: 50.0° x 38°
  • Temperature range: -10 to +150 °C
  • Focus: fix
  • Color Palettes: iron, Rainbow, Grayscale
  • Temperature accuracy: 3%.
Voltage reading range DC (min.) 0.1 V
Voltage DC reading range (max.) 1000 V
V AC reading range (min.) 0.1 V
V AC reading range (max.) 1000 V
Amperage reading range DC (min.) 0.1 A
A DC reading range (max.) 600 A
A AC reading range (min.) 0.1 A
Amperage reading range AC (max.) 600 A
Reading range - resistance 6000 K (±1.0%)
Reading range - capacity 1000 µF (± 1.0%)
