FLIR CM46 Clamp meter Digital CAT IV 300 V, CAT III 600 V Display (counts): 6000

  • Item no.: 1593916
  • Manufacturer no.: CM46
  • EAN: 0793950370469

The FLIR CM 4X Clamp Meter family comprises three professional and affordable true RMS multimeter for commercial and private electrician were developed. The CM 42 and CM 44 have an AC clamp measurement, and CM 46 provides both a AC/DC measurement to …

  • Warranty: 24 months
  • Manufacturer: FLIR
  • Item no.: 1593916
  • Manufacturer no.: CM46
  • EAN: 0793950370469

The FLIR CM 4X Clamp Meter family comprises three professional and affordable true RMS multimeter for commercial and private electrician were developed. The CM 42 and CM 44 have an AC clamp measurement, and CM 46 provides both a AC/DC measurement to …

  • Warranty: 24 months
  • Manufacturer: FLIR
Voltage reading range DC (min.) 0.1 V
Voltage DC reading range (max.) 600 V
V AC reading range (min.) 0.1 V
V AC reading range (max.) 600 V
Amperage reading range DC (min.) 0.1 A
A DC reading range (max.) 400 A
A AC reading range (min.) 0.1 A
Amperage reading range AC (max.) 400 A
Reading range - resistance 60 kΩ
Reading range - capacity 2500 µF
Frequency reading range 50 - 400 Hz
Temperature -40 to +400 °C
Basic accuracy 1.0 %
Measurement type True RMS
Power supply (details) 2 x AAA batteries (AAA)
Height 37 mm
Width 76 mm
Length 223 mm
Weight 243 g
Calibrated to
Manufacturer's standards (no certificate)
Reading category CAT IV 300 V , CAT III 600 V
Voltage metering AC/DC
Type CM46
Display Digital
Display (counts) 6000
Opening range of current clamps 30 mm
Product type Clamp meter

Technical data

Voltage reading range DC (min.) 0.1 V
Voltage DC reading range (max.) 600 V
V AC reading range (min.) 0.1 V
V AC reading range (max.) 600 V
Amperage reading range DC (min.) 0.1 A
A DC reading range (max.) 400 A
A AC reading range (min.) 0.1 A
Amperage reading range AC (max.) 400 A
Reading range - resistance 60 kΩ
Reading range - capacity 2500 µF
