Kemet T491C106K020ZT Tantalum capacitor SMD 10 µF 20 V DC 10 % (L x W x H) 6 x 3.2 x 2.5 mm 1 pc(s)

Item no.: 502154
Manufacturer no.: T491C106K020ZT
EAN: 2050000147715

Variants

B 45 196-H with particularly high volume capacity, for increased demands, eg information technology, data processing, measurement and control systems. Fixed electrolyte, for reflow (IR, vapour phase) and and wave soldering, taped in accordance with …

Full description

Warranty: 24 months
Manufacturer: Kemet

Item no.: 502154
Manufacturer no.: T491C106K020ZT
EAN: 2050000147715

Variants

B 45 196-H with particularly high volume capacity, for increased demands, eg information technology, data processing, measurement and control systems. Fixed electrolyte, for reflow (IR, vapour phase) and and wave soldering, taped in accordance with …

Full description

Warranty: 24 months
Manufacturer: Kemet

Technical data Description Downloads (1) Write New Review

IEC climate category: 55/125/56
Peak voltage: US 1,3 x UN
Failure rate (at 40 °C, RS ≥ 3 Ω/V) for CN
UN ≤ 330 µC: ≤ 8 fit ( ≤ 8
10-9 /h)
Failure rate (at 40 °C, RS ≥ 3 Ω/V) for CN
UN 330 µC: ≤ 24 fit ( ≤ 24
10-9 /h)

Type	SMD
Capacity (elec.)	10 µF
Nominal voltage	20 V DC
Tolerance ±	10 %
Material	Plastic
Lifespan	>500000 h
Length	6 mm
Width	3.2 mm
Height	2.5 mm
Content	1 pc(s)
Dim	(L x W x H) 6 x 3.2 x 2.5 mm
Type	T491C106K020AT+
Material (details)	Plastic housing, flame retardant (UK-94V-0)
Nominal voltage (details)	4-35 V
Capacity (elec.)	10 µF
Voltage	20 V DC
Product type	Tantalum capacitor

Technical data

IEC climate category: 55/125/56
Peak voltage: US 1,3 x UN
Failure rate (at 40 °C, RS ≥ 3 Ω/V) for CN
UN ≤ 330 µC: ≤ 8 fit ( ≤ 8
10-9 /h)
Failure rate (at 40 °C, RS ≥ 3 Ω/V) for CN
UN 330 µC: ≤ 24 fit ( ≤ 24
10-9 /h)

Type	SMD
Capacity (elec.)	10 µF
Nominal voltage	20 V DC
Tolerance ±	10 %
Material	Plastic
Lifespan	>500000 h
Length	6 mm
Width	3.2 mm
Height	2.5 mm
Content	1 pc(s)

Dim	(L x W x H) 6 x 3.2 x 2.5 mm
Type	T491C106K020AT+
Material (details)	Plastic housing, flame retardant (UK-94V-0)
Nominal voltage (details)	4-35 V
Capacity (elec.)	10 µF
Voltage	20 V DC
Product type	Tantalum capacitor

Documents & Downloads

Datasheet 502154 Kemet T491C106K020ZT Tantalum capacitor SMD 10 µF 20 V DC 10 % (L x W x H) 6 x 3.2 x 2.5 mm 1 pc(s)
PDF

Tantalum 'HighCap' chip capacitor

B 45 196-H with particularly high volume capacity, for increased demands, eg information technology, data processing, measurement and control systems. Fixed electrolyte, for reflow (IR, vapour phase) and and wave soldering, taped in accordance with IEC 60286-3.

Warranty: 24 months
Manufacturer: Kemet

Comments

For more information on this T491C106K020ZT capacitor, please see its datasheet under 'downloadable documents'.
