Omron G5LE-1-VD 12 VDC PCB relay 12 V DC 8 A 1 change-over 1 pc(s)
- Item no.: 503811
- Manufacturer no.: G5LE-1-VD 12 VDC
- EAN: 2050000801815
Mono-stable, compact PCB-relay. Is used in white goods, controls of all kinds!
- Warranty: 24 months
- Manufacturer: Omron
- Item no.: 503811
- Manufacturer no.: G5LE-1-VD 12 VDC
- EAN: 2050000801815
Mono-stable, compact PCB-relay. Is used in white goods, controls of all kinds!
- Warranty: 24 months
- Manufacturer: Omron
Technical data
- Creep resistance: PTI (CTI) > 250
| Type | G5LE-1-VD 12 VDC |
|---|---|
| Coil nominal voltage | 12 V DC |
| Control mode | monostable, 1 coil |
| R(coil) | 360 Ω |
| Contact type | 1 change-over |
| Contact material | AgSnO2 |
| Switching voltage (max.) | 125 V DC , 250 V AC |
| Switching current (max.) | 8 A |
| Max. switching capacity | 240 W , 1200 VA |
| Connection | Solder pins |
| Electrical lifespan | Min 100000 cycles |
|---|---|
| Durability | Min 10 x 106 cycles |
| Min. temperature | -40 °C |
| Max. temperature | +85 °C |
| Length | 22.5 mm |
| Width | 16.5 mm |
| Height | 19 mm |
| Content | 1 pc(s) |
| Insulation resistance | 500 V/DC - 100 MΩ |
| Nominal voltage (details) | 12 V DC |
| Switching capacity | 250 V/AC/10 A/30 V/DC/8 A |
| Switching voltage | Max 250 V/AC/125 V DC |
| Switching current | Max(AC) 10 A/(DC) 8 A |
| Dielectric strength | (Coil/contact) 2000 V/AC/(open contact) 750 V AC |
| Type | G5LE-1-VD 12 VDC |
| Ambient temperature | -40 - +85 °C |
| Coil rating | ~ 400 mW |
| Contact type | 1 CO, SPDT |
| Product type | PCB relay |
Documents & Downloads
Omron G5LE-1-VD 12 VDC PCB relay 12 V DC 8 A 1 change-over 1 pc(s)
Mono-stable, compact PCB-relay. Is used in white goods, controls of all kinds!
Highlights & Details
- VDE-certification
- Warranty: 24 months
- Manufacturer: Omron
Comments
Approvals: Certified by VDE according to EN61810-1, UL508 and CSA 22.2.Frequently bought together
