Omron G6A-274P-ST-US 12 VDC PCB relay 12 V DC 2 A 2 change-overs 1 pc(s)

  • Item no.: 503803
  • Manufacturer no.: G6A-274P-ST-US 12 VDC
  • EAN: 2050000801785

Sensitive, polarized relay with twin crossbar changeover contacts Flat, waterproof design Very low magnetic field

Full description
  • Warranty: 24 months
  • Manufacturer: Omron
  • Item no.: 503803
  • Manufacturer no.: G6A-274P-ST-US 12 VDC
  • EAN: 2050000801785

Sensitive, polarized relay with twin crossbar changeover contacts Flat, waterproof design Very low magnetic field

Full description
  • Warranty: 24 months
  • Manufacturer: Omron
Technical data Description Downloads (1) Write New Review
  • Surge voltage resistance: 1500 V
  • Sealed (RT III)
Type G6A-274P-ST-US 12 VDC
Coil nominal voltage 12 V DC
Control mode monostable, 1 coil
R(coil) 720 Ω
Contact type 2 change-overs
Contact material Ag + Au
Switching voltage (max.) 220 V DC , 250 V AC
Switching current (max.) 2 A
Max. switching capacity 60 W , 125 VA
Connection Solder pins
Electrical lifespan
Min 500000 cycles
Durability
Min 100 x 106 cycles
Min. temperature -40 °C
Max. temperature +70 °C
Length 20.2 mm
Width 10.1 mm
Height 8.4 mm
Dim (L x W x H) 20.2 x 10.1 x 8.4 mm
Content 1 pc(s)
Type monostabile
Insulation resistance 500 V/DC 1000 MΩ
Nominal voltage (details) 12 V DC
Switching capacity
Max 125 VA/60 W
Switching current (125 V/AC) 0.5 A/ (30 V/DC) 2 A
Dielectric strength 1000 V
Type G6A-274P-ST-US 12 VDC
Ambient temperature -40 - +70 °C
Max. permanent current 3 A
Contact type 2 CO, DPDT
Product type PCB relay

Technical data

  • Surge voltage resistance: 1500 V
  • Sealed (RT III)
Type G6A-274P-ST-US 12 VDC
Coil nominal voltage 12 V DC
Control mode monostable, 1 coil
R(coil) 720 Ω
Contact type 2 change-overs
Contact material Ag + Au
Switching voltage (max.) 220 V DC , 250 V AC
Switching current (max.) 2 A
Max. switching capacity 60 W , 125 VA
Connection Solder pins
