Panasonic DSP15FD PCB relay 5 V DC 5 A 1 maker, 1 breaker 1 pc(s)

  • Item no.: 1082465
  • Manufacturer no.: DSP15FD
  • EAN: 2050001891631

POWER RELAY DSP1-5V-F

Full description
  • Item no.: 1082465
  • Manufacturer no.: DSP15FD
  • EAN: 2050001891631

POWER RELAY DSP1-5V-F

Full description
Technical data Description Downloads (1) Write New Review
Type DSP15FD
Coil nominal voltage 5 V DC
Control mode monostable, 1 coil
R(coil) 83 Ω
Contact type 1 maker , 1 breaker
Contact material AgSnO2
Switching voltage (max.) 125 V DC , 250 V AC
Switching current (max.) 5 A
Max. switching capacity 150 W , 1250 VA
Connection Solder pins
Response time 10 ms
Fall time 5 ms
Durability 5 x 10 7 cycles
Min. temperature -40 °C
Max. temperature +65 °C
Length 20.2 mm
Width 11 mm
Height 10 mm
Dim (L x W x H) 20.2 x 11 x 10 mm
Content 1 pc(s)
Product type PCB relay

Technical data

Type DSP15FD
Coil nominal voltage 5 V DC
Control mode monostable, 1 coil
R(coil) 83 Ω
Contact type 1 maker , 1 breaker
Contact material AgSnO2
Switching voltage (max.) 125 V DC , 250 V AC
Switching current (max.) 5 A
Max. switching capacity 150 W , 1250 VA
Connection Solder pins
