Panasonic JQ1AP-B-12V-F PCB relay 12 V DC 10 A 1 maker 1 pc(s)
- Item no.: 1082467
- Manufacturer no.: JQ1APB12FT
- EAN: 2050001891655
POWER RELAY JQ1AP-B-12V-F
- Warranty: 24 months
- Manufacturer: Panasonic
- Item no.: 1082467
- Manufacturer no.: JQ1APB12FT
- EAN: 2050001891655
POWER RELAY JQ1AP-B-12V-F
- Warranty: 24 months
- Manufacturer: Panasonic
Technical data
| Type | JQ1AP-B-12V-F |
|---|---|
| Coil nominal voltage | 12 V DC |
| Control mode | monostable, 1 coil |
| R(coil) | 720 Ω |
| Contact type | 1 maker |
| Contact material | AgSnO2 |
| Switching voltage (max.) | 110 V DC , 250 V AC |
| Switching current (max.) | 10 A |
| Max. switching capacity | 150 W , 1250 VA |
| Connection | Solder pins |
| Response time | 20 ms |
|---|---|
| Fall time | 10 ms |
| Durability | 10 7 switching cycles |
| Min. temperature | -40 °C |
| Max. temperature | +85 °C |
| Length | 20 mm |
| Width | 10 mm |
| Height | 15.6 mm |
| Dim | (L x W x H) 20 x 10 x 15.6 mm |
| Content | 1 pc(s) |
| Product type | PCB relay |
Documents & Downloads
Power relay JQ
