Phoenix Contact 1774069 Screw terminal 10.00 mm² Number of pins 2 Green 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
10.16 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 3.28 / piece)
€ 172.27
-5 %
€ 163.86
plus VAT.
Highlights & Details
PCB terminal block MKDSP 10N/ 2-10,16 SZS
- Content 50 pc(s)
Technical specifications
- Type
MKDSP 10N/ 2-10,16 SZS
- Product type
Screw terminal
- Features
+ extractor sleeve
- CS
10.16 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
MKDSP
- Min. stripping length
10 mm
- Stripping length (max.)
10 mm
- Connection
Screw terminal
Print
- Nominal current
76 A
- Nominal current - rounded value
76 A
- Cross section (flexible) (max.)
10.00 mm²
- Cross section (inflexible) (max.)
10.00 mm²
- AWG (min.)
20
- Connector orientation
Parallel (to the PCB)
- AWG max.
6
- Contact material
Tin plated
- Factory colour
Green
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1774069
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
1000 V
- Width
34.30 mm
- Height
20.32 mm
- Length
18.40 mm
Documents & Downloads
Datasheet
Datasheet 568048 Phoenix Contact 1774069 Screw terminal 10.00 mm² Number of pins 2 Green 50 pc(s)
User & Safety Instructions
User & Safety Instructions 568048 Phoenix Contact 1774069 Screw terminal 10.00 mm² Number of pins 2 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 76 A, Nom. voltage: 1000 V, Pitch: 10.16 mm, Number of positions: 2, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °
Hints
Special order, no right of withdrawal.
