Siemens SSR 3RF20501AA24 50 A Switching voltage (max.): 460 V AC Zero crossing 1 pc(s)

SSR 3RF2, 1-phase, B=45mm, 50A 48-460V/110-230V AC

Solid state relays, 1-phase 3RF2 width 45 mm, 50 A 48-460 V / 110-230 V AC Screw terminals SIRIUS 3RF20 solid state relays for switching resistive/inductive loads, e.g. of radiators or valves in a filling plant.
The devices are wear-free and silent and are ideal for noise-sensitive areas (offices, hospitals). They are extremely reliable even at high switching frequencies. The compact design saves space on the cooling surface. The solid-state relays can also be expanded by simply clicking on the standardized 3RF29 function modules for a wide range of applications. The devices are approved worldwide (e.g. IEC and UL/CSA).
The solid-state relays are available as single-phase devices in two widths or as 3-phase devices. They are available for different power ratings and rated operating voltages. Designed for AC or DC operation, they are available with screw, spring-loaded or ring cable lug connection.
In addition to the 3RF29 function modules, control plugs and terminal covers are also available as accessories.
Simple, efficient, always up-to-date - the SIRIUS modular system.

This text is machine translated.

Highlights & Details

• Installation width 45 mm.
• This text is machine translated.

Comments

Please note that the product is a custom-made and therefore exempt from the returns policy. Special order, no right of withdrawal.
