Stroke drawing/circuit diagram
1/2
Stroke drawing/circuit diagram
Song Chuan 822E-1A 12VDC Automotive relay 12 V DC 40 A 1 maker
EAN:
Part number:
Item no:
Product type
Automotive relay
Coil nominal voltage
12 V DC
Contact type
1 maker
Connection
Print
Switching voltage (max.)
14 V DC
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 3.61
5
3% = € 0.11
€ 3.50
10
5% = € 0.18
€ 3.43
50
10% = € 0.37
€ 3.24
100
20% = € 0.73
€ 2.88
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 3.61 / piece)
€ 3.61
plus VAT.
Highlights & Details
Automotive relay 822E 40 A, 1 X AK
- Open design
- This text is machine translated.
Technical specifications
- Product type
Automotive relay
- Type
822E-1A 12VDC
- Features
w/o elbow mount
- Coil nominal voltage
12 V DC
- Contact type
1 maker
- Contact material
AgSnO
- Connection
Print
- Switching voltage (max.)
14 V DC
- Switching current (max.)
40 A
- Max. switching capacity
560 W
- Resistance (coil)
90 Ω
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Width
21.4 mm
- Height
21.8 mm
- Length
26.6 mm
- Dim
(L x W x H) 26.6 x 21.4 x 21.8 mm
- RoHS-compliant
- Nominal voltage (details)
12 VDC
- Type
822E-1A 12
Documents & Downloads
Datasheet
Datasheet 504016 Song Chuan 822E-1A 12VDC Automotive relay 12 V DC 40 A 1 maker
User & Safety Instructions
User & Safety Instructions 504016 Song Chuan 822E-1A 12VDC Automotive relay 12 V DC 40 A 1 maker
Description
Hints
Switch current information refers to peak current. Full details free to download from our comprehensive product documents library.
