TDK B84111AB120 EMI filter flame retardant 250 V AC 20 A 0.47 mH (L x W x H) 63.5 x 77 x 38.1 mm 1 pc(s)

  • Item no.: 501912
  • Manufacturer no.: B84111AB120
  • EAN: 2050000147050
Variants
0.47 mH 250 V AC 20 A 1.5 mH 250 V AC 3 A 1.8 mH 250 V AC 6 A

SIFI A, standard filter series, normal attenuation. Line filter for 1-phase systems.

Full description
  • Warranty: 24 months
  • Manufacturer: TDK
  • Item no.: 501912
  • Manufacturer no.: B84111AB120
  • EAN: 2050000147050
Variants
0.47 mH 250 V AC 20 A 1.5 mH 250 V AC 3 A 1.8 mH 250 V AC 6 A

SIFI A, standard filter series, normal attenuation. Line filter for 1-phase systems.

Full description
  • Warranty: 24 months
  • Manufacturer: TDK
Technical data Description Downloads (1) Write New Review
Features flame retardant
Connection Type C CEE 7/16 plug 6.3 mm
Mounting type Structure
Inductance (L) 0.47 mH
Nominal voltage 250 V AC
Nominal current 20 A
Nominal current - rounded value 20 A
Leakage current 0.5 mA
Type Flame-retardant moulded casing UL 94 V-0
Length 63.5 mm
Width 77 mm
Height 38.1 mm
Manufacturer part # B84111AB120
Type B84111AB120
Content 1 pc(s)
Dim (L x W x H) 63.5 x 77 x 38.1 mm
Connection Spade plug 6.3 mm
Leakage current (250 V/50 Hz) 0.5 mA
Nominal voltage (details) 115/250 V/50-60 Hz
Nominal current (details) 20 A
RoHS-compliant Yes
Product type EMI filter

Technical data

Features flame retardant
Connection Type C CEE 7/16 plug 6.3 mm
Mounting type Structure
Inductance (L) 0.47 mH
Nominal voltage 250 V AC
Nominal current 20 A
Nominal current - rounded value 20 A
Leakage current 0.5 mA
Type Flame-retardant moulded casing UL 94 V-0
Length 63.5 mm
