TracoPower DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 5 pc(s)
Item no:
Datasheet (PDF)
Total (€ 51.93 / piece)
€ 259.66
plus VAT.
14-day return policy included
Technical specifications
- Product type
DC/DC converter (print)
- Type
TEN 25-2411WI
- Nominal voltage
24 V DC
- Min. input voltage
10 V DC
- Input voltage (max.)
40 V DC
- No. of outputs
1 x
- Output voltages
5 V DC
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Efficiency (max.)
85 %
25 W
- Insulation voltage
1500 V DC
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 50.8 x 15.5 x 40.6 mm
- Height
40.6 mm
- Length
50.8 mm
- Width
15.5 mm
- Output voltage (max.)
5 V DC
- Output voltage (min.)
5 V DC
- Weight
48 g
- Content
5 pc(s)
Documents & Downloads
Datasheet
Datasheet 2791190 TracoPower DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 5 pc(s)
Datasheet 2791190 TracoPower DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 5 pc(s)
User & Safety Instructions
User & Safety Instructions 2791190 TracoPower DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 5 pc(s)
Warranty Terms
Warranty Terms 2791190 TracoPower DC/DC converter (print) 24 V DC 5 V DC 5 A 25 W No. of outputs: 1 x Content 5 pc(s)
Description
4:1 input range, short-circuit proof, external on/off, E/A-insulation 1500 V/DC, input filter according to EN 55022, class A.
