TracoPower DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 10 pc(s)
Item no:
Datasheet (PDF)
Total (€ 44.96 / piece)
€ 449.58
plus VAT.
Technical specifications
- Product type
DC/DC converter (print)
- Type
THD 15-4812N
- Nominal voltage
48 V DC
- Min. input voltage
36 V DC
- Input voltage (max.)
75 V DC
- No. of outputs
1 x
- Output voltages
12 V DC
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Efficiency (max.)
90 %
15 W
- Insulation voltage
1500 V DC
- Enclosure
DIL 24
- Connection
Solder pins
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 31.8 x 20.3 x 14 mm
- Height
14 mm
- Length
31.8 mm
- Width
20.3 mm
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Weight
14.4 g
- Content
10 pc(s)
Documents & Downloads
Datasheet
Datasheet 2791625 TracoPower DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 10 pc(s)
Datasheet 2791625 TracoPower DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 10 pc(s)
User & Safety Instructions
User & Safety Instructions 2791625 TracoPower DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 10 pc(s)
Warranty Terms
Warranty Terms 2791625 TracoPower DC/DC converter (print) 48 V DC 12 V DC 1.25 A 15 W No. of outputs: 1 x Content 10 pc(s)
Description
High power density in the DIL-24 metal housing, 2:1 input range, input/output insulation 1500 V/DC, external on/off, input filter according to EN 55022, class A, industry-standard pinning.
