TracoPower TXLN 018-124 AC/DC PSU module (+ enclosure) 0.75 A 18 W 24 V DC 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 25.20
3
4% = € 1.09
€ 24.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 25.20 / piece)
€ 25.20
plus VAT.
Only 2 Piece(s) available
Highlights & Details
AC/DC PSU Components
- Compact metal casing with screw terminals
- Universal power input 85-264 VAC
- Compliance with EN 61000-3-2
- Convection cooling
- Protection against short-circuit, overvoltage and overload
- Safety approvals according to IEC/EN/UL 62368-1
- This text is machine translated.
Technical specifications
- Product type
AC/DC PSU module (+ enclosure)
- Input voltage (max.)
264 V AC
- Max. output current
0.75 A
- Output current (max.) - rounded
750 mA
- Min. input voltage
85 V AC
- Dim
(L x W x H) 76.0 x 50.8 x 28.0 mm
- Output voltage (max.)
24 V DC
- Connection
Screw terminal
18 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
50 °C
- Operating temperature (min.)
-20 °C
- Weight
130 g
- Width
50.8 mm
- Height
28.0 mm
- Length
76.0 mm
- Type
TXLN 018-124
- MTBF
626000 h
- Output current (min.)
0 mA
- Output voltage (min.)
24 V DC
- PFC
No
