TRU COMPONENTS TC-R13-527D2B Pushbutton switch 14 V DC 20 A 1 x On/Off latch 1 pc(s)

  • Item no.: 1587919
  • Manufacturer no.: 1587919
  • EAN: 2050004958072

DRUCKSCHALTER R13-527D2B ROT TC

  • Item no.: 1587919
  • Manufacturer no.: 1587919
  • EAN: 2050004958072

DRUCKSCHALTER R13-527D2B ROT TC

  • Housing: Splash-water protected
  • Voltage light bulbs: 12 V/DC
Features Protruding
Casing/button colour Black
Functions latch
Lighting type Area illumination
Colour Red
Bulb type LED (monochrome)
Switch position 1 x On/Off
Contact type 1 breaker
Connection Type C CEE 7/16 plug 4.8 mm
Contact resistance Max. 50 mΩ
Switching voltage 14 V DC
Switching current (max.) 20 A
Dielectric strength 1500 V AC
Min. temperature -25 °C
Max. temperature +85 °C
Recess diameter 20.2 mm
Content 1 pc(s)
Insulation resistance 100 MΩ
RoHS-compliant Yes
Light colour Red
Type TC-R13-527D2B
Board thickness (max.) 2.5 mm
Product type Pushbutton switch

Technical data

  • Housing: Splash-water protected
  • Voltage light bulbs: 12 V/DC
Features Protruding
Casing/button colour Black
Functions latch
Lighting type Area illumination
Colour Red
Bulb type LED (monochrome)
Switch position 1 x On/Off
Contact type 1 breaker
Connection Type C CEE 7/16 plug 4.8 mm
Contact resistance Max. 50 mΩ
