TRU COMPONENTS 1587544 Toggle switch TC-R13-87B-02 250 V AC 10 A 1 x Off/On latch 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
1146 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.53
10
8% = € 0.19
€ 2.34
25
10% = € 0.26
€ 2.27
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.53 / piece)
€
Highlights & Details
Toggle switch 250 V AC 10 A 1 x Off/On SCI R13-87B-02 latch 1 pc(s)
Technical specifications
- Optional front panel cut-out (for front panel thicknesses): 30.4 x 22.2 mm (1.25 - 2 mm) or 30.8 x 22.2 mm (2 - 3 mm)
- Voltage light bulbs: 250 V
- Casing/button colour
Black
Green
- Functions
latch
- Lighting type
Area illumination
- Colour
Green
- Bulb type
Glow lamp
- Switch position
1 x Off/On
- Print motif
None
- Material
Polyamide
- Connection
Type C CEE 7/16 plug 4.8 mm
- Contact resistance
50 mΩ
- Switching voltage
250 V AC
- Switching current (max.)
10 A
- Dielectric strength
1500 V/AC 1 minute
- Front panel thickness
1.25 mm
- Content
1 pc(s)
- Insulation resistance
100 MΩ/500 V DC
- RoHS-compliant
Yes
- Front panel cut-out
30.2 x 22.2 mm
- Type
TC-R13-87B-02
- Product type
Toggle switch
Documents & Downloads
Datasheet
Datasheet 1587544 TRU COMPONENTS 1587544 Toggle switch TC-R13-87B-02 250 V AC 10 A 1 x Off/On latch 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1587544 TRU COMPONENTS 1587544 Toggle switch TC-R13-87B-02 250 V AC 10 A 1 x Off/On latch 1 pc(s)
Description
Rocker switch for 'snap-in' mounting. Approvals: UL, CSA.
Hints
Re switch position: content in parentheses describes the n/o and n/c contact constellation
