VOLTCRAFT VC890 OLED Handheld multimeter Digital OLED display, Data logger CAT III 1000 V, CAT IV 600 V Display (counts

  • Item no.: 1420547
  • Manufacturer no.: VC890 OLED
  • EAN: 2050003814843

This text is machine translated. 30 V a warning symbol appears in the display. The sturdy casing is splashed with soft rubberised cap and the 1000 V high power safety, the Warning tone on wrongly connected meter lead and impedance switchover, which r…

  • Item no.: 1420547
  • Manufacturer no.: VC890 OLED
  • EAN: 2050003814843

This text is machine translated. 30 V a warning symbol appears in the display. The sturdy casing is splashed with soft rubberised cap and the 1000 V high power safety, the Warning tone on wrongly connected meter lead and impedance switchover, which r…

  • Recording function: 1 reading/second
  • Low-pass filter (1kHz)
Voltage reading range DC (min.) 0.01 mV
Voltage DC reading range (max.) 1000 V
V AC reading range (min.) 0.0001 V
V AC reading range (max.) 1000 V
Amperage reading range DC (min.) 0.01 µA
A DC reading range (max.) 10 A
Reading range - resistance 0.01 Ω - 60 MΩ
Reading range - capacity 0,001 nF - 6000 µF
Frequency reading range 10 Hz – 60 MHz
DC resistance 10 MΩ
Basic accuracy 0.03 %
Measurement type True RMS
Frequency range 45 Hz - 100 kHz
Weight 380 g
Calibrated to
Manufacturer's standards (no certificate)
Reading category CAT III 1000 V , CAT IV 600 V
Voltage metering AC/DC
Current reading AC/DC
Type VC890 OLED
Display Digital
Display (counts) 60000
Features OLED display , Data logger
Temperature reading range (max.) +1000 °C
Temperature reading range (min.) -40 °C
Product type Handheld multimeter

Technical data

  • Recording function: 1 reading/second
  • Low-pass filter (1kHz)
Voltage reading range DC (min.) 0.01 mV
Voltage DC reading range (max.) 1000 V
V AC reading range (min.) 0.0001 V
V AC reading range (max.) 1000 V
Amperage reading range DC (min.) 0.01 µA
A DC reading range (max.) 10 A
Reading range - resistance 0.01 Ω - 60 MΩ
Reading range - capacity 0,001 nF - 6000 µF
Frequency reading range 10 Hz – 60 MHz
DC resistance 10 MΩ
