WAGO 289-722 WAGO 289-722 Interface Module D-subminiature Header 0.08 - 2.5 mm² 0.08 - 2.5 mm² Pins: 25 Content: 1 pc(s)
EAN:
Part number:
Item no:
Product type
Transfer module
Total no. of pins
25
Connection
Spring-loaded terminal
Dim
(W x H) 69 mm x 34 mm
Type
D-SUB female header
Datasheet (PDF)
Highlights & Details
D-SUB header interface module
- Mounting base for TS 35
- 289-722
Technical specifications
- Product type
Transfer module
- Total no. of pins
25
- Connection
Spring-loaded terminal
- Dim
(W x H) 69 mm x 34 mm
- Type
D-SUB female header
- Operating current
2 A
- Content
1 pc(s)
- Number of pins
25
- Width
69 mm
- Height
34 mm
- max. cross section
2.5 mm²
- Min. cross section
0.08 mm²
- RoHS-compliant
- Series
CAGE CLAMP® Serie 736
- Max. temperature
+50 °C
- Min. temperature
-20 °C
- Features
+ D-SUB pin strip
TS 35 socket
- Connection
Series 236 CAGE CLAMP®
- Material (details)
Connector contact: Au over 2 µm Ni
- Connector cross section
0.08 - 2.5 mm²
- Pins
25
- Connection
-
- Temperature range
-20 - +50 °C
- Operating voltage
125 V AC/DC
Documents & Downloads
Datasheet
Datasheet 741283 WAGO 289-722 WAGO 289-722 Interface Module D-subminiature Header 0.08 - 2.5 mm² 0.08 - 2.5 mm² Pins: 25 Content: 1 pc(s)
User & Safety Instructions
User & Safety Instructions 741283 WAGO 289-722 WAGO 289-722 Interface Module D-subminiature Header 0.08 - 2.5 mm² 0.08 - 2.5 mm² Pins: 25 Content: 1 pc(s)
Description
With D-subminiature header, mounting base for TS 35.
