Image similar
Image similar
WAGO 788-507 Relay component Nominal voltage: 115 V AC Switching current (max.): 16 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Product type
Relay component
Contact type
1 change-over
Nominal voltage
115 V AC
Switching voltage (max.)
250 V AC
Switching current (max.)
16 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
20
-
€ 17.64
60
5% = € 0.88
€ 16.76
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 20
Multiple: 20
Total (€ 17.64 / piece)
€ 352.80
plus VAT.
Highlights & Details
Plug base with miniature switching relay
Technical specifications
- Product type
Relay component
- Type
788-507
- Contact type
1 change-over
- Contact material
AgNi 90/10
- Nominal voltage
115 V AC
- Switching voltage (max.)
250 V AC
- Switching current (max.)
16 A
- Max. switching capacity
4000 VA
- Durability
10 x 106 Switching operations
IP20
- Max. temperature
+50 °C
- Min. temperature
-25 °C
- Length
86 mm
- Width
15 mm
- Height
54 mm
- Dim
(L x W x H) 86 x 15 x 54 mm
- Content
1 pc(s)
- Type
Plug base with miniature switching relay
- Nominal voltage (details)
115 V AC
- Nominal current (details)
16 A
- Switching voltage
250 V AC
- Dielectric strength
(Contact/coil) 5 kV/(open contact) 1 kV
- Type
788-507
- Ambient temperature
-25 - +50 °C
Documents & Downloads
Datasheet
Datasheet 504653 WAGO 788-507 Relay component Nominal voltage: 115 V AC Switching current (max.): 16 A 1 change-over 1 pc(s)
Datasheet 504653 WAGO 788-507 Relay component Nominal voltage: 115 V AC Switching current (max.): 16 A 1 change-over 1 pc(s)
Description
Plug base with miniature switching relay and operating display for rail mounting TS 35. Connection via tension spring terminals.
