Weidmüller 1224620000 Plug inset 12 Soldering 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug inset
Connection
Soldering
Total no. of pins
12
Number of pins
12
Content
1 pc(s)
Datasheet (PDF)
Number
Total (€ 12.60 / piece)
€ 15.12
-17 %
€ 12.60
plus VAT.
14-day return policy included
Technical specifications
- Net weight: 15 g
- Insulation resistance:> 1010 Ω
- Contact surface: Gold-plated
- Nominal current: 8 A
- Plug-in cycles:> 1000
- Operating temperature, max.: 125 °C
- Operating temperature, min.: -40 °C
- Contact material: Copper-zinc alloy
- Connection thread: M23
- Fire behavior: V-0
- Housing base material: Thermoplastic polyamide PA 6, PBT
- contact number / diameter: 12 x 1 mm
- Product type
Plug inset
- Connection
Soldering
- Total no. of pins
12
- Number of pins
12
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1774812 Weidmüller 1224620000 Plug inset 12 Soldering 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1774812 Weidmüller 1224620000 Plug inset 12 Soldering 1 pc(s)
Description
Contact insert for circular connectors to be installed in a housing.
