3D Xtech PTG02ES102000BK00 3DXSTAT Filament 1.75 mm 2000 g Black, Black 1 pc(s)

ESD PETG is an advanced ESD-safe connection, which has been developed for use in critical applications, which require protection against electrostatic discharge (ESD). Made using state-of-the-art multi-wall carbon nanotube technology, state-of-the-art compounding technology and precise extrusion processes.

Chemical resistance
Untensioned rods made of PETG have good resistance to diluted aqueous solutions of mineral acids, bases, salts and soaps as well as to aliphatic hydrocarbons, alcohols and a variety of oils. Halogenated hydrocarbons, short-chain ketones and aromatic hydrocarbons dissolve or source the plastic.

Typical applications are
Semi-con: Hard disk components, wafer handling, devices, housings and connectors
Industrial: Conveying, measuring and recording applications

Target conductivity for 3XSTAT ™ ESD PETG
10 ^ 7 to 10 ^ 9 ohms Surface resistance on a 3DP sample using a concentric ring test method.
Note: Internal studies have shown that elevated extruder temperatures can achieve a higher conductivity. Similarly, lower extruder temperatures have resulted in lower conductivity. Each printer is set up differently and has a different part geometry. So expect some testing time to understand how this filament works in your specific printer/application. However, please do not exceed 270 °C to reduce the risk of polymer degradation.

Surface conductivity as a function of the extruder temperature
The surface resistance of the printed ESD-safe part depends on the extruder temperature of the printer. For example, if your tests show that the part is too insulating, increasing the extruder temperature will improve conductivity. Therefore, the surface resistance can be adjusted up or down by adjusting the extruder temperature, depending on the measured value you get from your side.
