3M 92-NBA0 Resin cable jointing kit 1 Set
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
3M™ Scotchcast™ 92-NBA 0 cast resin fitting, 0,6/1 kV, 4x 1.5 - 4, 5x 1.5 - 2.5 mm²
- All products in this range use the one-component casting shell
- Offers time and cost savings through extra-fast setup
- Water repellent polyurethane resin
- Quick and clean installation thanks to the integrated casting port
- Fully transparent housing shell to secure the correct cable setting during installation
- Guarantees the highest level of electrical insulation for professional use
- RoHS and REACH compliant
Technical specifications
- Branch form: inLine
- The main cable diameter is 6 - 16 mm
- Max. Wire size: 4 mm²
- Min Wire size: 1.5 mm²
- Max. Outer diameter of insulation: 16 mm
- Min Outer diameter of insulation: 4 mm
- Product type
Resin cable jointing kit
- Content
1 Set
Documents & Downloads
Datasheet
Datasheet 3098727 3M 92-NBA0 Resin cable jointing kit 1 Set
Security datasheet
Security datasheet 3098727 3M 92-NBA0 Resin cable jointing kit 1 Set
Signal word
Danger
GHS / H Statements
- H 315: Causes skin irritation
- H 319: Causes serious eye irritation
- H 334: May cause allergies or asthma symptoms or breathing difficulties if inhaled
- H 317: May cause an allergic skin reaction
- H 351: Suspected of causing cancer(state type of exposure only if proven that no other exposure type may cause these defects)
- H 335: May cause respiratory irritation
- H 373: May cause damage to organs (name all organs affected if known) through prolonged or repeated exposure (name exposure type if there is compelling evidence that no other exposure type has the same effect)
GHS / P Statements
- P 261: Avoid inhaling dust/fume/gas/mist/vapours/spray
- P 280: Wear protective gloves/protective clothing/eye protection/face protection
- P 304+340: IF INHALED: Take person into fresh air and keep at rest in a position comfortable for breathing
- P 305+351+338: CONTACT WITH EYES: Rinse cautiously with water for several minutes. Remove contact lenses if applicable/possible. Continue rinsing
- P 332+313: SKIN IRRITATION: Seek medical advice
- P 342+311: If experiencing respiratory symptoms: contac Poison Control Center or seek medical advice
Description
The 3M™ Scotchcast™ Premium Resin Cable Connection Kits include Scotchcast™ Cable Resin 40, a high-quality, two-component polyurethane compound designed for general electrical insulation, moisture sealing and mechanical protection.
This text is machine translated.
This text is machine translated.
Hints
The 92-NBA Series 3M™ Scotchcast™ cast resin kit is designed for single- to five-wire unshielded low voltage plastic cables. It ensures the electrical insulation and mechanical protection of cable connections. The SVHC-free, tested as per EN 50393 Premium connecting set can be used indoors and outdoors or in the ground or under water. The transparent, one-part sealing shell can be folded together in no time at all and closes with automatic latching. In addition, pre-formed perforated foam gaskets are used. This means that up till now there is no need for a time-consuming use of saw and adhesive tape for a tight seal. When casting the supplied 3M™ Scotchcast™ casting resin 40, a GMG system (closed mixing and casting) is used. Thus, contact with the cast resin during processing is practically excluded. The transparent mixed-pack pouch guarantees visual control of the mixing process. After use, the mixed package pouch with the remains of hardened cast resin can be disposed of as normal household waste. Disposal in the form of special waste is not necessary.
