ABB 1SAM350000R1010 MS132-10 RCCB 1 pc(s)
Product type
RCCB
Connection
Screws
Factory colour
Multicolour
IP rating
IP20
Length
150 cm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
RCCB
- Connection
Screws
- Factory colour
Multicolour
IP20
- Length
150 cm
- Width
45 mm
- Height
86.75 mm
- Content
1 pc(s)
- Type
MS132-10
- Dim
(L x W x H) 150 cm x 45 mm x 86.75 mm
45
97.8 mm
86.5 mm
4 kW
10 A
3
230-690 V
6.3-10 A
IP20
Screw connection
Turn button
Built-in device fixed built-in technique
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2325466 ABB 1SAM350000R1010 MS132-10 RCCB 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2325466 ABB 1SAM350000R1010 MS132-10 RCCB 1 pc(s)
Description
Motor protection switch MS132 with thermal and electromagnetic protection stands for the compact and powerful series with hohem breaking capacity for motor protection up to 15 kW (400 V) with a module width of 45 mm. The temperature-compensated device has a rotary handle control with a clear switching position display I/TRIP/0. In addition, MS132 has a short-circuit display. The rotary handle can be locked directly with the help of a padlock in the 0 position. Auxiliary, signal and short-circuit signaling contacts as well as undervoltage and shunt trip units can be mounted without tools. 3-phase rails for 65 A or for 100 A and feed blocks for 25 mm² or 35 mm² permit the joint infeed of several motor circuit breakers. Protective housings as well as accessories for installation in control cabinets and doors complement the product range. ATEX certification allows the protection of motors in hazardous areas, UL approval as "Self protected Combination motor cotroller" extends the application area in North America.
This text is machine translated.
