ABB 1SCA115285R1001 OTM250E3M230C Circuit breaker 3-pin 250 A
Product type
Circuit breaker
Number of pins
3
Nominal current - rounded value
250 A
Nominal current
250 A
Factory colour
Black
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Circuit breaker
- Number of pins
3
- Nominal current - rounded value
250 A
- Nominal current
250 A
- Factory colour
Black
- Content
1 pc(s)
296
150 mm
181 mm
0
0
250 A
3
0-690 V
IP20
0
TRUE
TRUE
Bolt connection
FALSE
Short thumb-grip
FALSE
FALSE
FALSE
140 kW
8 kA
Black
TRUE
FALSE
FALSE
TRUE
FALSE
690 V
FALSE
FALSE
Built-in device fixed built-in technique
250 A
140 kW
FALSE
250
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2320767 ABB 1SCA115285R1001 OTM250E3M230C Circuit breaker 3-pin 250 A
User & Safety Instructions
User & Safety Instructions 2320767 ABB 1SCA115285R1001 OTM250E3M230C Circuit breaker 3-pin 250 A
Description
The motorized switch disconnectors of the OTM series are unique in their variety and flexibility. The OTM series switches current strengths from 40 A to 2500 A at voltages up to 1000 V AC. The maintenance-free motor is available in operating voltages from 110 V to 240 V AC and 24 V DC depending on the type. To ensure a high level of safety, the motors are protected against overcurrent with a fuse. Thanks to its compact design and simple wiring, the OTM series is suitable for numerous installations that require remote operation. In addition, the switch can be manually operated at any time. In addition, the OTM series has an IEC approval. ABB offers a wide range of accessories for these switches, such as Extension shafts, handles, auxiliary switches and terminal covers. The simple handling makes the OTM series an optimal solution for the most different applications.
