ABB 1SVR427031R0000 Rail mounted PSU (DIN) 1.25 A Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
100 V
- Inputs
1
- Input voltage (max.)
240 V
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Output type (power supply units)
Fixed voltage
- Dim
(W x H) 40.5 mm x 114 mm
- Output voltage (max.)
24 V DC
- Manufacturer part #
1SVR427031R0000
- Content
1 pc(s)
- Width
40.5 mm
- Height
114 mm
- Type
CP-E 24/1.25
- Efficiency
90 %
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2319546 ABB 1SVR427031R0000 Rail mounted PSU (DIN) 1.25 A Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2319546 ABB 1SVR427031R0000 Rail mounted PSU (DIN) 1.25 A Content 1 pc(s)
Description
The CP-E series includes models with output voltages of 5 V DC and 48 V DC with an output current of 0.625 A to 20 A. Thanks to the high thermal efficiency of up to 90% and the associated very low power loss and very low heating, the devices can be operated without forced cooling. The functionality has been extended, while at the same time the number of different models has been significantly reduced. Of course, the power supplies of the CP-E series are approved in accordance with all applicable international standards.
