ABB 2CDS253280R0045 S203C-B4 Circuit breaker 4 A 415 V
Product type
Circuit breaker
Number of pins
3
Release characteristics
B
Nominal current - rounded value
4 A
Nominal current
4 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Circuit breaker
- Number of pins
3
- Release characteristics
B
- Nominal current - rounded value
4 A
- Nominal current
4 A
- Content
1 pc(s)
- Nominal voltage
415 V
IP20
AC
35.6 mm
4 A
415 V
50-60 Hz
B
500 V
3
3
2
2
FALSE
IP20
3
1-16 mm²
1-10 mm²
-25-55 °C
FALSE
TRUE
3
6 kA
6 kA
6 kA
6 kA
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3118061 ABB 2CDS253280R0045 S203C-B4 Circuit breaker 4 A 415 V
User & Safety Instructions
User & Safety Instructions 3118061 ABB 2CDS253280R0045 S203C-B4 Circuit breaker 4 A 415 V
Description
The series S 200C circuit breakers protect cables and wires from overload and short circuit in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 and/or IEC/EN 60898-1 AND DIN VDE 0660-101 OR IEC/EN60947-2. Their connection terminal provides for simple and secure contact and handling by means of a double-directed cylinder lift connection. Wire cross-sections up to 16 mm² can be connected directly to the device via the terminal clamp with insulation in protection class IP20. The range of accessories of the G2C series offers flexible possibilities of fulfilling further tasks. This device offers you a three-pin protection in two division units (35.6 mm).
