ABB 2CDS271437R0087 S201MR-K0.2 Circuit breaker 0.2 A 400 V
Product type
Circuit breaker
Number of pins
1
Release characteristics
K
Nominal current - rounded value
200 mA
Nominal current
0.2 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Circuit breaker
- Number of pins
1
- Release characteristics
K
- Nominal current - rounded value
200 mA
- Nominal current
0.2 A
- Content
1 pc(s)
- Nominal voltage
400 V
IP20
AC
69 mm
0.2 A
400 V
50-60 Hz
K
440 V
3
3
3
1
FALSE
IP20
1
FALSE
0.75-35 mm²
0.75-25 mm²
-25-55 °C
FALSE
TRUE
1
10 kA
10 kA
15 kA
10 kA
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3114189 ABB 2CDS271437R0087 S201MR-K0.2 Circuit breaker 0.2 A 400 V
User & Safety Instructions
User & Safety Instructions 3114189 ABB 2CDS271437R0087 S201MR-K0.2 Circuit breaker 0.2 A 400 V
Description
The series S 200 MR circuit breakers protect cables and wires against overload and short circuit in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations, DIN VDE 0660-101 and/or IEC/EN60947-2, UL1077 and CSA 22.2 No. 235. The captive screw of the terminal opening for M5 ring terminals ensures constant connection. The extensive range of accessories offers you everything that you need WAS for your installation tasks. Each device is subjected to three-fold intensive tests for quality and performance before delivery.
