ABB 2CDS272517R0428 S202UDC-Z10 Circuit breaker 10 A 125 V
Product type
Circuit breaker
Number of pins
2
Release characteristics
Z
Nominal current - rounded value
10 A
Nominal current
10 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Circuit breaker
- Number of pins
2
- Release characteristics
Z
- Nominal current - rounded value
10 A
- Nominal current
10 A
- Content
1 pc(s)
- Nominal voltage
125 V
IP20
DC
69 mm
10 A
125 V
0-0 Hz
Z
440 V
3
3
3
2
FALSE
IP20
2
FALSE
0.75-25 mm²
0.75-16 mm²
-25-55 °C
FALSE
TRUE
2
14 kA
14 kA
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3114464 ABB 2CDS272517R0428 S202UDC-Z10 Circuit breaker 10 A 125 V
User & Safety Instructions
User & Safety Instructions 3114464 ABB 2CDS272517R0428 S202UDC-Z10 Circuit breaker 10 A 125 V
Description
The circuit breaker of the series S 200 U DC protect cables and wires against overload and short circuit in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0660-101 and/or IEC/EN60947-2 and UL489 and/or CSA 22.2 No. 5. For better visibility of wiring, the connection opening for wires is above the connection opening for the phase rail. Wire cross-sections up to 25 mm² can be connected directly to the device via the terminal clamp with insulation in protection class IP20. The combination of approvals according to UL489, CSA 22.2 No. 5 and IEC/EN60947-2 make this device a globally applicable device for high requirements and is subjected before delivery to three-fold intensive tests for quality and performance.
This text is machine translated.
This text is machine translated.
