ABB 2CDS273001R0537 S203M-K32 Circuit breaker 3-pin 32 A 400 V
Product type
Circuit breaker
Number of pins
3
Release characteristics
K
Nominal current - rounded value
32 A
Nominal current
32 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Circuit breaker
- Number of pins
3
- Release characteristics
K
- Nominal current - rounded value
32 A
- Nominal current
32 A
- Factory colour
Grey
- Content
1 pc(s)
- Switch-off capacity
10 kA
- Nominal voltage
400 V
- Depth
69 mm
- Weight
0
AC/DC
69 mm
32 A
400 V
50-60 MHz
K
440 V
3
3
3
3
FALSE
10.8 W
IP20
3
FALSE
0.75-35 mm²
0.75-25 mm²
-25-55 °C
FALSE
TRUE
3
10 kA
10 kA
25 kA
25 kA
4
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2324660 ABB 2CDS273001R0537 S203M-K32 Circuit breaker 3-pin 32 A 400 V
User & Safety Instructions
User & Safety Instructions 2324660 ABB 2CDS273001R0537 S203M-K32 Circuit breaker 3-pin 32 A 400 V
Description
The circuit breakers of the series S 200 M protect cables and lines against overload and short-circuit according to DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN60947-2 and UL1077 and CSA 22.2 No. 235. Its patented terminal clamp provides for simple and safe contact and handling by means of a pressure plate. For better visibility when wiring, the connection opening for cables is above the connection opening for the phase rail. Conductor cross-sections up to 35 mm² can be connected directly to the device via the terminal clamp with insulation in protection class IP20. The extensive range of accessories offers you everything was needed for your installation tasks. Numerous approvals make the S 200 M fit for worldwide use. Each device is subjected to three times intensive tests for quality and performance before delivery.
