ABB 2CSB202199R1400 RCCB RCD (all types of current) 40 A
Product type
RCCB
Number of pins
2
Nominal current - rounded value
40 A
Nominal voltage (details)
230 V
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Nominal voltage (details)
230 V
- Product type
RCCB
- Number of pins
2
- Content
1 pc(s)
- Nominal current
40 A
- Nominal current - rounded value
40 A
- Model
RCD (all types of current)
40 A
500 V
2
FALSE
0 ms
A
0.03-0.03 A
230-230 V
50/60 Hz
IP2X
25-25 mm²
25-25 mm²
TRUE
-25-55 °C
FALSE
FALSE
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3118780 ABB 2CSB202199R1400 RCCB RCD (all types of current) 40 A
Description
The FI block (RCU) is for customer-facing installation with circuit breakers of the S200 series. The following FI/LS combinations (RCBOs) provide personal and property protection as well as protection against electrically ignited fires according to DIN VDE 0100-410 and DIN VDE 0100-530. They protect 1P+N, 2P, 3P, 3P+N or 4P circuits against overload and short circuit currents, protection against sinusoidal AC and pulsating currents with a smooth DC fault current up to 6 mA against earth. Fault protection (protection in case of indirect contact), additional protection and fire protection. They comply with the product standard IEC 61009 Annex G, IEC 61009-2-1.
Areas of application are commercial and industrial applications. The extensive range of accessories offers you everything that you need WAS for your installation tasks.
The DDA200A 110V series is used especially for 110 V AC to 230 V AC applications.
The approval is RINA (IT).
This text is machine translated.
Areas of application are commercial and industrial applications. The extensive range of accessories offers you everything that you need WAS for your installation tasks.
The DDA200A 110V series is used especially for 110 V AC to 230 V AC applications.
The approval is RINA (IT).
This text is machine translated.
