ABB 2CSF202701R3400 F202B+40/0,3 RCCB RCD (all types of current) B+ 40 A 0.3 A 230 V
Product type
RCCB
Number of pins
2
Release characteristics
B+
Differential current rating
0.3 A
Nominal current - rounded value
40 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
RCCB
- Number of pins
2
- Release characteristics
B+
- Differential current rating
0.3 A
- Nominal current
40 A
- Nominal current - rounded value
40 A
- Model
RCD (all types of current)
- Content
1 pc(s)
- Nominal voltage
230 V
DIN rail
AC
69 mm
40 A
230 V
500 V
2
0.3 A
B+
FALSE
1 kA
3 kA
2
2
TRUE
FALSE
50 Hz
IP2X
25-25 mm²
0-25 mm²
TRUE
TRUE
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3115694 ABB 2CSF202701R3400 F202B+40/0,3 RCCB RCD (all types of current) B+ 40 A 0.3 A 230 V
Description
F200 type B+ for smooth direct fault currents and enhanced, preventive fire protection
All current sensitive, 10 ms short time delayed, 3 kA surge proof
Residual current circuit breakers (RCCs) provide personal protection and property protection as well as protection from electrical fires according to DIN VDE 0100-410 and DIN VDE 0100-530.
The F200 B+ series residual current circuit breakers ensure protection against earth in the case of sinusoidal AC currents, pulsating currents and smooth DC fault currents. Fault protection (protection in case of indirect contact), additional protection (with IΔn ≤ 30 mA) and fire protection (with I∆n ≤ 300 mA). It fulfills the product standards for RCDs type A IEC/EN 61008-1, 61543-2-1, 61008 (VDE 0664 10, 11, 30) and for type B+ DIN VDE 0664-400.
They are mainly used in commercial and industrial applications. The extensive range of accessories offers you everything that you need WAS for your installation tasks. The RCCB type B+ detect smooth DC fault currents, react earlier than the RCCB type B with max. 420 mA and have a frequency range of 0 ... 20 kHz for detecting the residual current. They therefore offer enhanced, preventive fire protection (extended fire protection according to DIN VDE 0100-530) for e.g. fire-endangered operational areas and commercial units.
