ABB 2CSF204196R3630 F204A-63/0,3/16,7H RCCB A 63 A 0.3 A 400 V
Product type
RCCB
Number of pins
4
Release characteristics
A
Differential current rating
0.3 A
Nominal current - rounded value
63 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
RCCB
- Number of pins
4
- Release characteristics
A
- Differential current rating
0.3 A
- Nominal current
63 A
- Nominal current - rounded value
63 A
- Content
1 pc(s)
- Nominal voltage
400 V
DIN rail
AC
69 mm
63 A
400 V
500 V
4
0.3 A
A
FALSE
1 kA
2
4
FALSE
FALSE
Other
IP2X
25-25 mm²
0-25 mm²
TRUE
TRUE
4 kV
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3118893 ABB 2CSF204196R3630 F204A-63/0,3/16,7H RCCB A 63 A 0.3 A 400 V
Description
F200 type A 16.7 Hz for AC-railway applications and switch heating
Residual current circuit breakers (RCCs) provide personal protection and property protection as well as protection from electrical fires according to DIN VDE 0100-410 and DIN VDE 0100-530. The residual current circuit-breakers of series F200 ensure protection in case of sinusoidal AC currents and pulsating currents with a smooth DC-fault share of up to 6 mA against earth. Fault protection (protection in case of indirect contact), additional protection (with IΔn ≤ 30 mA) and fire protection (with I∆n ≤ 300 mA). They meet the product standards IEC/EN 61008-1, 61008-2-1, 61543.
Operational areas are AC-railway applications and switch heating. The extensive range of accessories offers you everything that you need WAS for your installation tasks. The RCCB F200 16.7 Hz operates at a rated frequency of 16.7 Hz, which is common in AC railway applications and switch heating.
This text is machine translated.
Residual current circuit breakers (RCCs) provide personal protection and property protection as well as protection from electrical fires according to DIN VDE 0100-410 and DIN VDE 0100-530. The residual current circuit-breakers of series F200 ensure protection in case of sinusoidal AC currents and pulsating currents with a smooth DC-fault share of up to 6 mA against earth. Fault protection (protection in case of indirect contact), additional protection (with IΔn ≤ 30 mA) and fire protection (with I∆n ≤ 300 mA). They meet the product standards IEC/EN 61008-1, 61008-2-1, 61543.
Operational areas are AC-railway applications and switch heating. The extensive range of accessories offers you everything that you need WAS for your installation tasks. The RCCB F200 16.7 Hz operates at a rated frequency of 16.7 Hz, which is common in AC railway applications and switch heating.
This text is machine translated.
