ABB 2CSM631043R0811 Bell transformer 63 V 2.6 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Bell transformer
- Mounting type
DIN rail
- Operating voltage
230 V
- Output voltages
63 V
- Max. nominal current
2.6 A
- Width
87.5 mm
- Height
58 mm
- Length
44 mm
- Dim
(L x W x H) 44 x 87.5 x 58 mm
87.5
85 mm
58 mm
TRUE
IP20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2323197 ABB 2CSM631043R0811 Bell transformer 63 V 2.6 A
User & Safety Instructions
User & Safety Instructions 2323197 ABB 2CSM631043R0811 Bell transformer 63 V 2.6 A
Description
These transformers are conditionally short-circuit proof. They are equipped with a thermal protection device that automatically restores power when the transformer has cooled down sufficiently. They are ideal for the continuous power supply of measuring devices, electronic auxiliary devices (e.g. Measurement, video door entry systems, BUS communication) and circuits with low voltages (SELV) for bathrooms and showers, lighting, wells, electro-medical devices and the like.
