ABB A43 112-100 2CMA100244R1000 Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
EAN:
Part number:
Item no:
Product type
Electricity meter (3-phase)
Display
Digital
Calibration
Calibrated
Counter type
electronic
Display
Digital
Datasheet (PDF)
Technical specifications
- Counter type
electronic
- Product type
Electricity meter (3-phase)
- Display
Digital
- Calibration
Calibrated
- Display
Digital
- MID-approved
Yes
- Reading type
Active energy
- Current (max.)
5 A
- Current range
5 A (max)
- Type
A43 112-100
DRA (DIN-rail adapter)
123
Direct measurement
26.5 mm
65 mm
0.807 W
50-60 MHz
7
IP20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2319571 ABB A43 112-100 2CMA100244R1000 Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2319571 ABB A43 112-100 2CMA100244R1000 Electricity meter (3-phase) Digital MID-approved: Yes 1 pc(s)
Description
Three-phase meter for measuring a three-wire or four-wire three-phase power supply via a direct connection up to a maximum of 80 A. The following values are output via a white backlit display with up to 7 digits: Active energy (class 1), power, currents, voltages (L-L; L-N) and frequency, both for each phase and overall.Communication can be performed via the integrated interface RS485 (Modbus RTU) or via the infrared interface for connecting a KNX module. The energy meter has an output. This can be used as pulse output for the output of active energy or as alarm output. Up to 25 alarm values (threshold values with time delay) can be set here. Counter is calibrated according to MID and approved according to IEC. The installation width is 7 DIN modules.
