ABB CR-P024AC2G Interface relay Switching current (max.): 8 A 2 change-overs 1 pc(s)
Product type
Interface relay
Contact type
2 change-overs
Switching voltage (max.)
250 V DC/AC
Switching current (max.)
8 A
Type
CR-P024AC2G
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Interface relay
- Type
CR-P024AC2G
- Connection
Solder lug
- Max. pick-up voltage
24 V AC
- Contact type
2 change-overs
- Switching voltage (max.)
250 V DC/AC
- Switching current (max.)
8 A
- Features
pluggable
IP67
- Length
29 mm
- Width
12.7 mm
- Height
15.7 mm
- Dim
(L x W x H) 29 x 12.7 x 15.7 mm
- Content
1 pc(s)
8 A
12.7 mm
15.7 mm
29 mm
FALSE
Polarized
Mono stable
FALSE
Single contact
FALSE
Soldering flag connection
24-24 V
24-24 V
Other
IP67
FALSE
Other
AC
0
0
2
Documents & Downloads
Datasheet
Datasheet 3111334 ABB CR-P024AC2G Interface relay Switching current (max.): 8 A 2 change-overs 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3111334 ABB CR-P024AC2G Interface relay Switching current (max.): 8 A 2 change-overs 1 pc(s)
Description
As an interface, interface relays connect the electronic control level, for example PLC, to the level of sensors/actuators. Here they take over various functions: Switching of direct or alternating current loads with different ohmic, inductive and capacitive proportions, switching in the voltage range from a few mV to 250 V, switching in the current strength range from a few mA to 16 A, amplification of weak control signals, potential separation of control and load circuits as well as signal multiplication. The CR-P series has 9 different coil voltages with 1-2 changeover contacts. Two socket versions are available: Standard socket and logical socket. Plug-in function modules such as reverse polarity protection / snubber diode, LED module, RC links, overvoltage protection or time modules add to the range of applications on pluggable PCB relays.
